W-122/W-122P

W-122 is a two-way all-weather line array sound reinforcement system with exquisite appearance, compact structure, high sound pressure and high fidelity. *W-122 is equipped with our latest DSP switching mode amplifier module, which can be controlled online. *W-122 can be installed in a variety of combinations. which can be flexibly and conveniently used in all type of applications. *The W-122 cabinet is finished with high-grade black polyurethane paint, which is waterproof and super wear-resistant. The hanging hardware and front grille have undergone tensile strength tests and salt spray tests, making the speaker system suitable for all-weather applications. * W-122 is a bass reflex line array loudspeaker composed of a 4-inch neodymium tweeter and two 12-inch neodymium woofer. The cabinet is made of birch-wood, with a compact structure layout, symmetrical LF speakers, tweeters center.It is also equipped with a magnetic suspension system, which is safe and quick to install. * Applications:            auditorium           Stadium           club           mobile performance

TECHNICAL PARAMETERS
ModelW-122&W-122P（Active）
TypeTwo-way line array system
Frequency Response55Hz-20KHz±3dB
Power handlingLF 1000W(RMS)4000W(PEAK)
HF 120W(RMS)480W(PEAK)
SensitivityLF 108dB(1W@1M)
HF 110dB(1W@1M)
Max SPLLF 138dB(PEAK)
HF 140dB(PEAK)
DriversLF 2×12″(310mm) neodymium woofer 75mm(3in)coil
HF 1×4″ neodymium compression driver with 100mm titanium diaphragm
Nominal impedanceLF 8 ohm
HF 8 ohm
Coverage120°H×15°V
ConnectionsLF 1(+)1(-) HF 2(+)2(-)
Connectors2×NL4MP speakon
PHYSICAL PARAMETERS
Finishpolyurea coatings
Enclosure MaterialBirch Plywood
CrossoverLF  55Hz-800Hz    HF 800Hz-20KHz
Dimensions800×355×550mm(W×H×D)
Packing Dimensions875×455×620mm(W×H×D)0.246cbm
Net weight42.5kg (W-122) /47.5kg(W-122P)
Gross weight52kg (W-122) /57 kg(W-122P)
POWER AMPLIFIER PARAMETERS
Amplifier typeSwitching mode amplifier,class D circuit
Power Output(RMS)2X1200W/8ohm
Weight5kg
ConfigurationThe amp moduie is built inside W-122P

W-310&W-180/W-310P&W-180P

W-310&W-180 is a three-way line array system with exquisite appearance, compact structure and high sound pressure. W-310&W-180 is equipped with a newly developed DSP digital power amplifier module, which allows online test adjustment. W-310&W-180 is equipped with a variety of hoisting modes, which can be flexibly and conveniently transported, stacked, hoisted, supported, for various scenarios.

TECHNICAL PARAMETERS
ModelW-310&W-310P（Active）
Type Three-way line array system
Frequency Response65Hz-18KHz±3dB
Power handlingLF 700W(RMS)2800W(PEAK)
MF+HF 250W(RMS)1000W(PEAK)
SensitivityLF 103dB(1W@1M)
MF+HF 107dB(1W@1M)
Max SPLLF 132dB(PEAK)
MF+HF 138dB(PEAK)
DriversLF 2×10″(260mm) neodymium woofer75mm(3in)coil
MF 1×8″(210mm) neodymium woofer 50mm(2in)coil
HF 2×3″ neodymium compression driver with 75mm titanium diaphragm
Nominal impedanceLF 8 ohm
MF+HF 8 ohm
Coverage80°H×10°V
ConnectionsLF 1(+)1(-) MF+HF 2(+)2(-)
Connectors2×NL4MP speakon
PHYSICAL PARAMETERS
FinishTextured high-density polyurethane coating
Enclosure MaterialBirch Plywood
CrossoverLF  65Hz-250Hz    MF+HF 250KHz-18KHz
Dimensions700×310×520mm(W×H×D)
Packing Dimensions590×780×410mm(W×H×D)0.19cbm
Net weight40kg(W-310)/44kg(W-310P)
Gross weight44kg(W-310)/48kg(W-310P)
POWER AMPLIFIER PARAMETERS
Amplifier typeSwitching mode amplifier, class D circuit
Power Output (RMS)2X900W/8ohm
Weight3.6kg
ConfigurationThe amp module is built inside W-310P
TECHNICAL PARAMETERS
Model W-180&W-180P（Active）
Type Line array subwoofer system
Frequency Response35Hz-200Hz±3dB
Power handling1000W(RMS)4000W(PEAK)
Sensitivity 102dB(1W@1M)
Max SPL136dB(PEAK/1M)
Driver1×18″(460mm) woofer 100mm(4in)coil
Nominal impedance8 ohm
Connectors2×NL4MP speakon
PHYSICAL PARAMETERS
FinishTextured high-density polyurethane coating
Enclosure MaterialBirch Plywood
Dimensions700×520×780mm(W×H×D)
Packing Dimensions770×590×860mm(W×H×D)/0.39cbm
Net weight63.5kg(W-180)/66kg(W180P)
Gross weight67.5kg(W-180)/70kg(W180P)
POWER AMPLIFIER PARAMETERS
Amplifier typeSwitching mode amplifier, class D circuit
Power Output (RMS)DSP 900W/8ohm
Weight2.6kg
ConfigurationThe amp module is built inside W-180P





Keywords:outdoor sound systemSound systemProfessional speakerline array speakerLive soundprofessional audiosound equipmentstage

W-4 & W-4P

W-4&W-4P is a line array system which is made of two 12″ woofers, two 3″ titanium neodymium compression drivers and high-performance low-distortion compression driver with innovative horn design of wave phase philosophy. Wherever low frequency extension is required.

TECHNICAL PARAMETERS   技术参数
Model 型号W-4&W-4P（Active）
Type 类型Two-way line array system
Frequency Response 频率响应60Hz-18KHz±3dB
Power handling 功率LF 1200W(RMS)4800W(PEAK)
HF 240W(RMS)960W(PEAK)
Sensitivity 灵敏度LF 106dB(1W@1M)
HF 109dB(1W@1M)
Max SPL 最大声压LF 133dB(PEAK)
HF 135dB(PEAK)
Drivers单元LF 2×12″(310mm) neodymium woofer 75mm(3in)coil
HF 2×3″ neodymium compression driver with 75mm titanium diaphragm
Nominal impedance 阻抗LF 16 ohm
HF 16 ohm
Coverage 覆盖范围110°H×10°V
Connections 音箱连接LF 1(+)1(-) HF 2(+)2(-)
Connectors 输入连接2×NL4MP speakon
PHYSICAL PARAMETERS   物理参数
Finish 表面处理polyurea coatings
Enclosure Material箱体材料Birch Plywood
Crossover 分频建议LF  60Hz-1.5KHz   HF 1.5KHz-20KHz
Dimensions 外形尺寸840×341×458mm(W×H×D)
Packing Dimensions 包装尺寸920×420×540mm(W×H×D)0.21cbm
Net weight 净重40.5kg (W-4) /43.5kg(W-4P)
Gross weight 毛重50kg (W-4) /53 kg(W-4P)
POWER AMPLIFIER PARAMETERS   功放参数
Amplifier type 模块类型Switching mode amplifier,class D circuit
Power Output(RMS)额定功率2X900W/8ohm
2X1300W/4ohm
Weight 重量3.6kg
Configuration 配置The amp moduie is built inside W-4P
